1-3oz Copper Impedance Control Multilayer PCB With Blue Mask Gold Plating

Name: 1-3oz Copper Impedance Control Multilayer PCB With Blue Mask Gold Plating
Brand: Shenzhen Hengxunda Circuit Technology Co.,LTD
SKU: HS6025
Price: 2.10 USD
Availability: InStock

Product Details

Place of Origin: china

Brand Name: hengsheng

Certification: UL, ROHS,SGS,ISO9001

Model Number: HS6025

Payment & Shipping Terms

Minimum Order Quantity: 1pcs

Price: USD 0.1-5/pcs

Packaging Details: 25kgs/carton, vacuumed packing

Delivery Time: 7-10 days

Payment Terms: T/T, Western Union,paypal

Supply Ability: 100000pcs per month

Get Best Price

Product Details

Product Description

Highlight:

Finished:	Gold Platting	Board Thickness:	0.2-3.2mm
Copper Thickness:	1-3oz	Impedance Control:	Yes
Layer Count:	2-20	Material:	FR-4, FR-1, CEM-1, CEM-3
Min. Hole Size:	0.2mm	Min. Line Spacing:	0.075mm
Min. Line Width:	0.075mm	Shipping Way:	DHL, FedEx, UPS, TNT, EMS
Silkscreen Color:	White, Black, Yellow	Solder Mask Color:	Green, Blue, White, Black, Red
Surface Finish:	HASL, ENIG, OSP, Immersion Gold

Finished:	Gold Platting
Board Thickness:	0.2-3.2mm
Copper Thickness:	1-3oz
Impedance Control:	Yes
Layer Count:	2-20
Material:	FR-4, FR-1, CEM-1, CEM-3
Min. Hole Size:	0.2mm
Min. Line Spacing:	0.075mm
Min. Line Width:	0.075mm
Shipping Way:	DHL, FedEx, UPS, TNT, EMS
Silkscreen Color:	White, Black, Yellow
Solder Mask Color:	Green, Blue, White, Black, Red
Surface Finish:	HASL, ENIG, OSP, Immersion Gold

1-3oz Copper Impedance Control Multilayer PCB With Blue Mask Gold Plating

Process Capability And Checking Parameters(Hard Board)
NO	ITEM	Technical Capabilities
1	Layers	1-38L
2	Max.Board Size	1200*610mm
		48"*24"
3	Finished Board Thickness	0.2mm--10.0mm
		0.008"--0.4"
4	Finished Copper Thickness	17um-420um
		0.5OZ--12OZ
5	Min.Trace Width/Space	0.075mm/0.065mm
		0.003"/0.0026"
6	Min.Hole Size	0.15mm
		0.006"
7	Hole Dim. Tolerance(PTH)	±0.05mm
		±0.002"
8	Hole Dim.Tolerance(NPTH)	±0.05mm
		±0.002"
9	Drill Location Tolerance	±0.05mm
		±0.002"
10	V-Cut Degrees	20-90 ºC
		20DEG-90DEG
11	Min.V-Cut PCB Thickness	0.4mm
		0.016"
12	N/C Routing Tolerance	±0.1mm
		±0.004"
13	Min.Blind/Buried Via	0.15mm
		0.06"
14	Plug Hole Size	0.2mm--0.6mm
		0.008"--0.024"
15	Min.BGA PAD	0.2mm
		0.008"
16	Materials	FR4(TG130-TG170),Aluminium,Halogen-free,Rogers,ShengYi,KB

17	Surface Finish	HASL-LF,ENIG,ImAg,ImSn,OSP,Gold platting, ENIG+OSP,HAL+G/F

18	Warp & Twist	≤0.75%

19	Electrical Testing	50--300V

20	Solderability Testing	245±5ºC,3sec Wetting area least95%

21	Thermal Cycling Testing	288±5ºC,10sec,3cycles

22	Ionic Contamination Testing	Pb,Hg,Cd,Cr(VI),PBB,PBDE six items are less than 1000ppm

23	Soldmask Adhesion Testing	260ºC+/-5, 10S,3times
