Product Details
Place of Origin: china
Brand Name: hengsheng
Certification: UL, ROHS,SGS,ISO9001
Model Number: HS4015
Payment & Shipping Terms
Minimum Order Quantity: 1pcs
Price: USD 0.1-5/pcs
Packaging Details: 25kgs/carton, vacuumed packing
Delivery Time: 7-10 working days
Payment Terms: T/T, Western Union,paypal
Supply Ability: 100000pcs per month
Blind/Buried Vias: |
Yes |
Board Thickness: |
1.6mm |
Copper Thickness: |
1oz |
Impedance Control: |
Yes |
Layer: |
4 |
Material: |
FR4 |
Min Annular Ring: |
6mil |
Min Clearance Between Pads: |
4mil |
Min Hole Size: |
0.2mm |
Min Solder Mask Bridge: |
4mil |
Min Solder Mask Dam: |
4mil |
Min Trace Width/Space: |
4/4mil |
Silkscreen Color: |
White |
Solder Mask Color: |
Green |
Surface Finish: |
ENIG, AU=2U"=0.05UM |
Blind/Buried Vias: |
Yes |
Board Thickness: |
1.6mm |
Copper Thickness: |
1oz |
Impedance Control: |
Yes |
Layer: |
4 |
Material: |
FR4 |
Min Annular Ring: |
6mil |
Min Clearance Between Pads: |
4mil |
Min Hole Size: |
0.2mm |
Min Solder Mask Bridge: |
4mil |
Min Solder Mask Dam: |
4mil |
Min Trace Width/Space: |
4/4mil |
Silkscreen Color: |
White |
Solder Mask Color: |
Green |
Surface Finish: |
ENIG, AU=2U"=0.05UM |
| Process Capability And Checking Parameters(Rigid PCB) | |||||||
| NO | ITEM | Technical Capabilities | |||||
| 1 | Layers | 1 Layer-38 Layer | |||||
| 2 | Max.Board Size | 1200mm*610mm /48"*24" | |||||
| 3 | Finished Board Thickness | 0.2mm--10.0mm / 0.008"--0.4" | |||||
| 4 | Finished Copper Thickness | 17um-420um / 0.5OZ--12OZ | |||||
| 5 | Min.Trace Width/Space | 0.075mm-0.065mm / 0.003"-0.0026" | |||||
| 6 | Min.Hole Size | 0.15mm / 0.006" | |||||
| 7 | Hole Dim. Tolerance(PTH) | ±0.05mm / ±0.002" | |||||
| 8 | Hole Dim.Tolerance(NPTH) | ±0.05mm / ±0.002" | |||||
| 9 | Drill Location Tolerance | ±0.05mm / ±0.002" | |||||
| 10 | V-Cut Degrees | 20-90 ºC / 20DEG-90DEG | |||||
| 11 | Min.V-Cut PCB Thickness | 0.4mm / 0.016" | |||||
| 12 | N/C Routing Tolerance | ±0.1mm / ±0.004" | |||||
| 13 | Min.Blind/Buried Via | 0.15mm / 0.06" | |||||
| 14 | Plug Hole Size | 0.2mm--0.6mm / 0.008"--0.024" | |||||
| 15 | Min.BGA PAD | 0.2mm / 0.008" | |||||
| 16 | Materials | FR4(TG130-TG170),Aluminium,Halogen-free, Rogers,ShengYi,KB,Guoji | |||||
| 17 | Surface Finish | HASL-LF,ENIG,ImAg,ImSn,OSP,Gold platting, ENIG+OSP,HAL+G/F | |||||
| 18 | Warp & Twist | ≤0.75% | |||||
| 19 | Electrical Testing | 50--300V | |||||
| 20 | Solderability Testing | 245±5ºC,3sec Wetting area least95% | |||||
| 21 | Thermal Cycling Testing | 288±5ºC,10sec,3cycles | |||||
| 22 | Ionic Contamination Testing | Pb,Hg,Cd,Cr(VI),PBB,PBDE six items are less than 1000ppm | |||||
| 23 | Soldmask Adhesion Testing | 260ºC+/-5, 10S,3times | |||||
